BR22/14 CYLINDRICAL Brush Drive 22″

SKU: 686016

$6,343.65 $5,873.75

Solution Tank Size:14 Gal

Brush Pressure: 79Lbs.

Power Source:Battery

1 year warranty from Atlanta

You can strip floors using Janilink Auto Scrubbers

Click here to see a Demonstration



22″ Janilink Battery Auto Scrubber

BR22/14 – Brush Drive – Cylindrical

Brush Pressure: 79 lbs.

Speed: 9,740 Sq. Ft per Hour


ModelBR 22/14Brush RPM1300
L X W X H50 X 24 X 42Brush Pressure79 lbs.
Net Weight223 lbs.Cleaning Path22
Solution/ Recovery Tank14 / 15 gal.Cleaning Rate (Sq. Ft per Hour)9,740
Squeegee Width33Vacuum Motor0.6 hp
Tank ConstructionPoly-enthyleneBrush Motor0.6 hp
Brush TypeCylindricalSound Level67 dB
Brush Width22Voltage24
* Specifications are subject to change without notice.

Simple Operator Interface

Easy-to-understand user interface dramatically reduces time and resources spent on training

Heavy Duty Squeegee

Super-durable squeegee assembly with a quick-change feature. Squeegee is designed to endure even the harshest of cleaning environments.

Solution Control

Electronic solenoid avoids accidental solution flow.

Complete View

Low profile sight line of machine improves operator’s view of cleaning space.

Easy Access

Easy access and removal of vacuum motor for simplified maintenance and increased machine up-time.

Four Point Machine Stance

Two front and rear wheels deliver extra stability and balance.

 > Features and Benefits of the BR and BD 18/11
  • Medium walk-behind unit suited for schools,hotels, retail shops, restaurants, and hospitals
  • BR unit has a 22″ cleaning path
  • 14 gallon solution tank
  • Simple operator interface
  • Whisper Quiet 67 dB
  • Heavy-duty, four-sided, parabolic squeegee
  • Ergonomic handle design
  • Exceptionally durable rotomolded polyethylene construction
  • Stainless steel battery tray
  • Manual adjustment of brush pressure

Parabolic Squeegee

Heavy duty assembly featuring a four-sided rear blade with quick release lever to facilitate squeegee

changes in 10 seconds or less! This ensures a lower cost of ownership.

Easy to Clean

Quick release recovery tank lid for easy tank rinsing and filling.

Vacuum Motor Protection

Automatic recovery tank float shutoff device to avoid foam and water from damaging vacuum motors

Easy Maintenance

A sturdy hood strut keeps lid open during maintenance, allowing easy access to batteries, vacuum motors

and hoses.

Quick Brush Change

Deck shroud peals back allowing easy access to change brushes.

Manual Levers for

Greater Reliability

Our walk-behind models feature long lasting,all-manual levers that raise and lower decks.

TIP: When scrubbing extremely dirty floors, operate the machine with vaccum motor off and squeege blade up to allow chemicals to penatrate dirty surfaces. After thoroughly scrubbing floor, then pick up solution.
Weight350 lbs
Dimensions40 × 48 × 48 in
SKU: 686016 Category:
